AXAGON SuperSpeed USB-C Hub USB-hub - USB 3.2 - 6 porter - Svart

Multiport USB-C 3.2 Gen 1 hub AXAGON HMC-6H4A expands your laptop, computer or phone with six ports. You can easily and quickly connect up to four USB devices and an HDMI display to your computer at the same time via the double-sided USB-C connector. You also get the possibility to supply your laptop using Power Delivery technology. The USB-C hub provides a simple and compact 6-in-1 docking station for notebooks like the MacBook Pro.

The USB hub offers four USB outputs with standard USB-A connectors. The hub can also handle permanent connection of several external drives simultaneously. Transfer rate is up to 5 Gbit/s thanks to the fast USB 3.2 Gen 1 interface.

The USB-C connector is dedicated to powering a mobile phone or laptop using Power Delivery 3.0 technology with up to 100 W. Connect a suitable USB-C Power Delivery charger to the hub and then connect the hub to the laptop. This saves one USB-C port. The condition is a laptop with Power Delivery charging support from the USB-C port and a suitable PD charger.

The HDMI output provides high-quality images up to 4K/30 Hz Ultra HD resolution and supports multi-channel audio transmission. Popular gaming resolutions WQHD 2560 × 1440 at 60 Hz or Full HD 1920 × 1080 at 60, 100, and 120 Hz maximum are also supported. A DisplayPort Alternate Mode (DP Alt Mode) enabled USB-C port or Thunderbolt 3 port is necessary for proper video output function.

The elegant aluminium body ensures mechanical resistance and quality cooling. The glossy upper part with a subtle backlit logo underlines the premium look of the hub.

The port replicator is an ideal accessory for laptops without USB-A connectors or video output. You can use your existing USB peripherals without having to purchase new ones. Thanks to Plug and Play and Hot Plug functions, connecting the hub is simple without complicated installation, and peripherals can also be easily connected or disconnected while the computer is running. The hub can also be connected to phones with a USB-C connector, allowing connection of a flash drive, keyboard, mouse, monitor, TV, or projector.

Input:

• 1× USB 3.2 Gen 1 / SuperSpeed USB port, USB-C male connector
• Backward compatible with USB 3.1 Gen 1 / USB 3.0 / USB 2.0
• Compatible with Thunderbolt 3
• USB-C male connector on a fixed 20 cm cable

USB outputs:

• 4× SuperSpeed USB port, USB-A female connector
• 1× USB-C Power Delivery port (charging only), USB-C female connector
• Supports transmission rates 5 Gbit/s / 480 Mbit/s / 12 Mbit/s / 1.5 Mbit/s (SuperSpeed / High / Full / Low speed)
• Total bandwidth/transmission rate determined by the USB 3.2 Gen 1 interface (theoretical up to 5 Gbit/s)
• USB-C hub can handle simultaneous connection of multiple external drives
• Charging of mobile devices (including iPad) with a current of up to 1.5 A/5 V from USB-A and USB-C ports

HDMI output:

• 1× HDMI A female connector
• Maximum supported resolution: 4K 4096 × 2160 at 30 Hz, WQHD 2560 × 1440 at 60 Hz, Full HD 1920 × 1080 at 60, 100, 120 Hz
• DisplayPort Alternate Mode (DP Alt Mode) enabled USB-C port or Thunderbolt 3 port required
• HPD (Hot-Plug-Detect) support
• TMDS (Transition Minimized Differential Signalling) support
• HDCP 1.4 and 2.3 support
• Supports up to 8-channel LPCM audio, compressed audio (AC-3, DTS), and HBR audio formats
• Supports sample rates up to 192 kHz and up to 24-bit audio (depending on source and end device)

Power Delivery:

• Power Delivery 3.0 support – device power supply from wall charger via USB-C hub
• Maximum output 100 W (20 V / 5 A)
• Requires PD support from device and a suitable PD wall charger

Other features:

• Hot Plug support allows device connection while running
• Full Plug and Play support
• Standby mode support
• Power via USB bus or PD wall charger
• Heavy-duty aluminium body for better cooling; heat dissipation is improved
• Backlit logo indicates connection to the computer
• High-quality shielded cable ensures high communication speed and minimal interference
• Dimensions 110 × 35 × 12 mm
• Weight 54 g (incl. cable)
• USB-C cable length 20 cm

Supported operating systems:

• Windows 10 / 11, macOS, Linux, Android, Chrome OS
• Compatibility depends on OS and device manufacturer support
• Drivers included with supported OS; no additional installation required
• DisplayPort Alternate Mode support depends on updated OS and device manufacturer

Package contains:

• USB-C hub with fixed 20 cm cable
• Multilingual manual (CZ / DE / DK / ENG / ESP / FIN / FR / GR / HR / HU / IT / NL / PL / PT / RO / RU / SK / SWE / BG / CN / TR / ARA)
• Packed in a cardboard box with hanging hole
