Varenummer: 3394841

Chieftec VEGA M PPG-750-C Strømforsyning (PSU) - 750 Watt - 135 mm - ATX - 80 Plus Gold sertifisert

The CHIEFTEC Vega M Series power supply is built to Intel’s ATX 12V 3.1 standard and supports PCIe GEN5 with 80PLUS Gold certified efficiency. It prioritizes a competitive price-to-performance ratio up to 850W while maintaining the trusted Chieftec quality. The Vega M Series features LLC Half-Bridge converter with DC-to-DC technology to provide enhanced power efficiency and stability.

The full-modular design with extra- long black cables make it suitable for mainstream gamers to build their system, even in larger PC cases. Additionally, its 135mm fluid dynamic bearing (FDB) silent fan optimizes the balance between cooling performance and noise levels.

  • Compliant with ATX 12V 3.1
  • Support PCIe GEN5
  • 80PLUS Gold certified efficiency
  • LLC Half-Bridge converter with DC to DC technology
  • Fully modular cable management






903,00 kr 722,40 kr eksl. mva
Rimeligste private frakt: 109,00 kr
Fjernlager, 5-7 dager til forsendelse

The Chieftec VEGA M PPG-750-C power supply is designed for efficiency and reliability. With a total output of 750 W, this power supply meets the demands of modern computing systems. Its fully modular cable management system allows users to customize their setup, reducing clutter and enhancing airflow. Equipped with a robust cooling system featuring a 135 mm fan, this unit operates quietly while maintaining optimal thermal performance.

Safety and compliance are important, with the Chieftec VEGA M meeting multiple standards such as RoHS and TUV Rheinland certification. Overcurrent, overvoltage, overload, and short-circuit protections ensure secure operation, safeguarding connected components. With features like active Power Factor Correction and DC-DC technology, this power supply delivers stable and efficient performance across a range of applications, making it an ideal choice for both gaming rigs and professional builds.

Strømkabel (intern)

Produsent
Varenummer
3394841
Model
PPG-750-C
Ean
0753263078896
Til produsentens hjemmeside
Total strøm
750 W
AC-inngangsspenning
100 - 240 V
AC-inngangsfrekvens
50/60 Hz
Power Factor Correction (PFC) type
Aktiv
Kombinert strøm (+3.3V)
100 W
Kombinert strøm (+5V)
100 W
Max output current (+3.3V)
20 A
Max output current (+12V1)
62,5 A
Max output current (+5V)
20 A
Max output current (-12V)
0,3 A
Strømkontakt for hovedkort
20+4 pin ATX
Perifere (Molex) strømkontakter (4-pin)
3
Hovedkort strømkabellengde
60 cm
Antall SATA-strømtilkoblinger
6
SATA kraftledning lengde
400 mm
Peripheral (Molex) strømkabellengde
400 mm
EPS strømtilkobling (8-pin)
Ja
EPS strømkontakt (4+4-pin)
Ja
PCI Express-strømtilkobling (6+2-pin)
4
PCI Express-strømkontakter (12+4-pinners)
1
PCI Express-strømkontakter (12+4-pinners) kabellengde
600 mm
CPU strømtilkobling (4+4-pin)
Ja
CPU kraftledning lengde
65 cm
ATX strømtilkobling (24-pin)
Ja
ATX strømtilkobling (20+4-pin)
Ja
Kabeltype
Fullt modulær
Formål
PC
Strømforsyningsenhetens formfaktor
ATX
80 PLUS-sertifisering
80 PLUS Gold
ATX-versjon
3.1
Bæreteknologi
FDB
Produktfarge
Svart
Form for nedkjøling
Aktiv
Viftediameter
13,5 cm
Belysning
Nei
Sertifisering
80PLUS Gold
Bredde
150 mm
Dybde
150 mm
Høyde
85 mm
Vekt
1,96 kg
Pakkevekt
2,43 kg

Energihåndtering

Total strøm
750 W
AC-inngangsspenning
100 - 240 V
AC-inngangsfrekvens
50/60 Hz
Power Factor Correction (PFC) type
Aktiv
Kombinert strøm (+3.3V)
100 W
Kombinert strøm (+5V)
100 W
Max output current (+3.3V)
20 A
Max output current (+12V1)
62,5 A
Max output current (+5V)
20 A
Max output current (-12V)
0,3 A

Tilkoblingsevne

Strømkontakt for hovedkort
20+4 pin ATX
Perifere (Molex) strømkontakter (4-pin)
3
Hovedkort strømkabellengde
60 cm
Antall SATA-strømtilkoblinger
6
SATA kraftledning lengde
400 mm
Peripheral (Molex) strømkabellengde
400 mm
EPS strømtilkobling (8-pin)
Ja
EPS strømkontakt (4+4-pin)
Ja
PCI Express-strømtilkobling (6+2-pin)
4
PCI Express-strømkontakter (12+4-pinners)
1
PCI Express-strømkontakter (12+4-pinners) kabellengde
600 mm
CPU strømtilkobling (4+4-pin)
Ja
CPU kraftledning lengde
65 cm
ATX strømtilkobling (24-pin)
Ja
ATX strømtilkobling (20+4-pin)
Ja
Kabeltype
Fullt modulær

Ytelse

Formål
PC
Strømforsyningsenhetens formfaktor
ATX
80 PLUS-sertifisering
80 PLUS Gold
ATX-versjon
3.1
Bæreteknologi
FDB

Design

Produktfarge
Svart
Form for nedkjøling
Aktiv
Viftediameter
13,5 cm
Belysning
Nei

Sertifikater

Sertifisering
80PLUS Gold

Vekt og dimensjoner

Bredde
150 mm
Dybde
150 mm
Høyde
85 mm
Vekt
1,96 kg

Datainnpakking

Pakkevekt
2,43 kg

Ovenstående informasjon/spesifikasjoner er veiledende og kan uten varsel bli endret av produsenten. Det tas forbehold om trykkfeil og illustrerende bilder. Enkelte tekster kan være autogenerert eller maskinoversatt, så derfor kan det forekomme tekster som virker misvisende.
